Design substations and MV rooms with this premium MV-SWG Substation Medium Voltage Switchgear Revit family. It is built entirely from native Revit geometry, so it looks realistic in 3D and renders while staying clean and readable in plans and elevations.

Key features:

• Fully parametric with only three parameters: Width, Depth and Height
• Default size: 4000 mm wide x 1200 mm deep x 2400 mm high
• Flexes cleanly when dimensions change, with no formulas and no broken constraints
• Five-panel switchgear lineup on a steel plinth, finished in blue-grey paint, with ribbed side panels
• Low voltage relay compartments with protection relays, digital meters, indicator lights, selector switches, push buttons and key locks
• Breaker compartments with inspection windows, operating sockets, voltage presence indicators (VPIS) and mimic diagram lines
• Bolted cable compartment covers with warning labels and danger plates
• Heavy-duty hinges and panel handles on every door
• Pressure-relief flaps on the roof
• Panel tags (INCOMER 01, METERING, OUTGOING 01 to 03), “DANGER 11 kV” plates and “MV-SWG MEDIUM VOLTAGE SWITCHGEAR” nameplate
• Realistic embedded materials: painted steel, galvanized steel, inspection glass, rubber gaskets, dark plastic, display glass and indicator lenses
• No imported CAD, no external links and no unnecessary parameters
• Category: Electrical Equipment, compatible with Revit 2020 and newer

Ideal for:
Substations, utility and MV rooms, hospitals, data centers, factories, industrial plants, airports and infrastructure projects.

What you get:

• MV-SWG – Substation Medium Voltage Switchgear.rfa (Revit 2020)
